SCX4-IP66-SUR - IP66 Wet Location 4" Superior Architectural Linear Surface Mounted Lights

SCX4-IP66-SUR - IP66 Wet Location 4" Superior Architectural Linear Surface Mounted Lights

Technical Specs

• Voltage: 120-277VAC 50/60Hz
• Wattage: 40W-160W
• Power Factor: >0.95
• LPW: 105
• Total Harmonic Distortion: ? 19 %
• 6FT. Lead 18/5 AWG SJTW on One Side
• 1FT. Lead 18/5 AWG SJTW on The Other Side For Daisy Chaining. The Cord Can be Tucked in If Not Needed, Weatherproof 1/2” NPT Plug Provided to Cover The Hub.
• All Wires Are Capped
• Two Steel Compression Connectors Provided.
• Surface Mounting Brackets with Screws & Anchors Included
• Low Profile Modern Design
• Aluminum Housing With Sandy White Finish
• Mounting Options: Surface
• IP Rating: IP66 Wet Location Only
• Operating Temperature: -22°F to +104°F
• 5-Year Warranty
• MCTP: Multi Color Temperature and Power (Selectable Switch On Fixture)
• Dimmable: 0~10V Dimming
• Total Lumens: 8400LM Max.
• Color Temperatures: 3500K/4000K/5000K
• Multi-CCT(Selectable Switch Inside Fixture)
• Color Rendering Index: CRI ? 80
• 50,000 Hours Rated Life
• Beam Angle: 105°(H) x 103.7°(V)

Applications

• Ideal for offices, hotels, corridors, saloons, libraries, meeting rooms, conference halls, and the best solution for modern lighting solutions
